Honeywell ipc354sb-adnf28k-i0 4MP Ir Dome Network Camera

Product Description

The HONEYWELL ipc354sb-adnf28k-i0 is a 4MP LightHunter fixed IR dome network camera built for continuous indoor IP surveillance. It uses a 1/2.7-inch CMOS sensor to deliver up to 2688 x 1520 resolution at 30 frames per second with Ultra 265, H.265, H.264, and MJPEG compression support. The 120 dB true wide dynamic range (WDR) engine produces clear images in high-contrast lighting conditions. Smart IR illumination reaches up to 30 meters, and the built-in microphone eliminates the need for external audio hardware. This camera is installed by security integrators, low-voltage technicians, and licensed alarm contractors on commercial and residential IP video systems.

This dome camera is designed for fixed indoor ceiling or wall installations where wide-angle or standard coverage is required. The 2.8 mm fixed lens delivers a 101.1-degree horizontal field of view, making it well suited for hallways, lobbies, retail floors, and open office spaces. Intelligent smart intrusion prevention functions — including cross-line detection, intrusion detection, enter-area detection, and leave-area detection — use target classification to reduce false alarms triggered by environmental movement such as leaves, birds, or lighting changes, and focus detection on humans, vehicles, and non-motor vehicles. People flow counting and crowd density monitoring are also supported natively.

Key Features

• 4MP CMOS sensor with up to 2688 x 1520 resolution at 30 fps; triple-stream output supported
• 120 dB true WDR for clear imaging in scenes with strong backlighting or mixed lighting
• Smart IR illumination up to 30 meters at 850 nm wavelength with auto/manual light control
• Intelligent intrusion prevention with human, vehicle, and non-motor vehicle target classification
• Built-in microphone with two-way audio support; G.711U and G.711A audio compression
• MicroSD edge storage up to 512 GB; supports ANR and NAS (NFS) network storage
• PoE (IEEE 802.3af) and DC 12V power input; max power consumption 4.5 watts
• 9:16 corridor mode supported; pan 3 to 360 degrees, tilt 0 to 68 degrees adjustment range

Compatibility

Compatible with ONVIF Profile S, Profile G, Profile T, and Profile M platforms. Supports API and SDK integration. Client software includes EZStation and mobile app access. Web browser live view is supported on IE 10 and later, Chrome 45 and later, Firefox 52 and later, and Edge 79 and later with plug-in; plug-in-free live view is available on Chrome 57 and later, Firefox 58 and later, and Edge 16 and later.

Installation Notes

Installation should be performed by a licensed low-voltage technician or security systems integrator familiar with IP camera deployment and PoE network infrastructure. Before mounting or wiring, de-energize the PoE switch port or disconnect the DC 12V supply. Verify network switch compliance with IEEE 802.3af before connecting. Local codes and NEC Article 725 requirements for low-voltage wiring should be followed throughout the installation.

Technical Specifications

• Max Resolution: 4 MP (2688 x 1520)
• Sensor: 1/2.7-inch CMOS
• Frame Rate: Up to 30 fps at 4 MP
• Video Compression: Ultra 265, H.265, H.264, MJPEG
• WDR: 120 dB
• Min. Illumination: 0.003 Lux color (F1.6, AGC ON); 0 Lux with IR
• IR Distance: 30 meters (98.4 feet)
• IR Wavelength: 850 nm
• Focal Length: 2.8 mm (101.1 degrees H) or 4.0 mm (83.5 degrees H)
• Lens Type: Fixed
• Adjustment Angle: Pan 3 to 360 degrees, Tilt 0 to 68 degrees, Rotate 3 to 360 degrees
• Edge Storage: MicroSD, up to 512 GB
• Audio: Built-in microphone, 1 audio input, 1 audio output, two-way audio supported
• Network Interface: 1 x RJ45 10M/100M Base-TX Ethernet
• Power: DC 12V plus or minus 25%, PoE IEEE 802.3af
• Power Consumption: Max 4.5 watts
• Dimensions: 4.3 inches diameter x 2.4 inches height
• Weight: 0.49 pounds
• Material: Metal and plastic
• Working Temperature: -30 degrees F to 140 degrees F
• Humidity: 95% RH or less, non-condensing
• Surge Protection: 4 KV
• Certifications: CE-EMC, FCC Part 15 B, CE LVD, CB, UL/CUL, CE-RoHS, WEEE
• ONVIF Compliance: Profile S, Profile G, Profile T, Profile M

Standard Information

• Brand: HONEYWELL
• Manufacturer Part Number: ipc354sb-adnf28k-i0
