Honeywell HVFD3D3D0100G100C 3G SmartVFD 10 HP 600 VAC

Product Description

The Honeywell 3G SmartVFD (HVFD3D3D0100G100C) is a controller designed for HVAC systems. It operates at 10 horsepower and supports an input voltage of 600 VAC. The controller features an 11-amp, NEMA 1 keypad equipped with a graphical display for easy navigation. Communication options include RS-485, BACnet, Modbus, FLN, and N2, facilitating integration into various systems. This unit includes start-up wizards to simplify commissioning and offers automatic motor adaptation, making it efficient and user-friendly.

• 10 HP, 600 VAC control capability
• NEMA 1 keypad with graphical display
• Multiple communication protocols supported

Product Highlights

This product is ideal for HVAC applications, such as controlling pumps, fans, and compressors. Its intuitive interface helps users navigate settings with ease.

Product Information

Standard Information

• Brand: Honeywell
• MPN: HVFD3D3D0100G100C

Technical Specifications

• Horsepower: 10 HP
• Input Voltage: 600 VAC
• Output Current: 11 Amp
• Enclosure Rating: NEMA 1
• Communication: RS-485, BACnet, Modbus, FLN, N2
• Power: 7.5 kW
