Honeywell HP970B1015/U Pneumatic Humidistat 65-95% RH Replacement MPN

Product Description

The Honeywell HP970B1015/U is a pneumatic humidistat designed for accurate humidity control. This device operates in a range from sixty-five to ninety-five percent relative humidity in five percent increments. It uses two-pipe connections and features a reverse acting action to provide proportional control of pneumatic valves for humidification or dehumidification systems.

• Straight set point scales for easy adjustment.
• Nylon element ensures durability and reliability.
• Plug-in air connections simplify installation.

Product Highlights

This humidistat is ideal for controlling humidity in commercial buildings and HVAC applications, ensuring optimal environmental conditions.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: HP970B1015/U

Technical Specifications

• Application: Humidity control
• Airflow Usage: 0.011 scfm (5.2 mL/s)
• Dimensions: Three and one-quarter inches high x two inches wide x one and five-eighths inches deep
• Maximum Safe Operating Pressure: 25 psi
• Temperature Range: 45°F to 125°F
• Number of Pipes: 2
• Scale Markings: 65 to 95% RH
• Throttling Range: 3 to 15% RH
