Hoffman E8PB Pushbutton Enclosures Type 12, 8Pbx30.5mm

Product Description

The HOFFMAN E8PB pushbutton enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches. This enclosure is a Type 12, made of steel with a gray, powder-coated finish. It features factory stamped 4-way pushbutton holes and external welded-on mounting brackets for easy installation.

• Seams continuously welded and ground smooth
• Captivated cover screws thread into sealed wells
• External welded-on mounting brackets for easy installation

Product Highlights

Durable steel enclosure with oil-resistant gasket and grounding stud for industrial applications.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: E8PB
• Country of Origin: Mexico

Technical Specifications

• Article Number: 57840
• Material: Steel
• Finish: Powder Coated
• Color Code: ANSI 61
• Thickness: 14ga
• Hole Size: 1.2in
• Hole Quantity: 8
• NEMA Rating: 12/IP65
• Outlets: 8
• Cover: Hinged
• Application: 30.5 or 22.5 mm Pushbuttons, Industrial
• Type: Pushbutton Enclosure
• Series: PB1
• Mounting Type: Wall
• BABA Compliant: No
• Sold as: PIECE
