Hoffman E3PBX Push Button Encl, Extra Deep, 3Pb X 30.5Mm

Product Description

The Hoffman E3PBX is an extra-deep pushbutton enclosure designed to hold 30.5-mm and 22.5-mm pushbuttons and switches, with added depth to accommodate additional pushbutton contact blocks. It features factory stamped 4-way pushbutton holes and external wall-mounting brackets. Seams are continuously welded and ground smooth.

• Constructed from 16 or 14 gauge steel
• Features captivated cover screws that thread into sealed wells
• Includes an oil-resistant gasket

Product Highlights

This Hoffman pushbutton enclosure provides a robust housing for pushbuttons and switches, ensuring protection and reliable performance in various industrial applications.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: E3PBX
• Country of Origin: US

Technical Specifications

• Brand: Hoffman
• Type: 12
• Material: Steel
• Description: Extra-Deep 30.5-mm & 22.5-mm Pushbutton Enclosures
• Manufacturers Part Number: E3PBX
• Gauge: 14 ga
• Hole Size: 30.5 mm in
• Number of Holes: 3
• Dimension T: 3.75 in
• Dimension Y: 1.86 in
• Overall L x W: 9.00 x 4.22 in
• Mounting G x H: 8.50 x 3.12 in
• Height: 8in
• Depth: 4.75in
• Finish: Powder Coated
• Color Code: ANSI 61
• Hole Quantity: 3
• Mounting: 8.50 x 3.12in
• Overall Dimensions: 9.00 x 4.22in
• UPC: 783510581404
• EAN: 8713574322806
• Standard Packaging Quantity: 1
• Packing Quantity: 1
• Bulletin Number: PB1
• Color Coding: ANSI 61
• Cover Type: Screw
• Size: 3PB x 30.5mm
• GTiN: 00783510581404
• Product UPC: 78351058140
• Used With: 30.5 mm and 22.5 mm Pushbuttons and Switches
• Length: 8-1/2 Inch
