Hoffman A1412CH Continuous Hinge Enclosure 14x12x6

Product Description

The Hoffman A1412CH continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications. The enclosure is made of steel with a polyester powder painted finish. It features a continuous hinge and external wall-mounting brackets for easy installation.

• Secure closure
• Continuous hinge
• Screw-down clamps

Product Highlights

The Hoffman A1412CH enclosure is ideal for various applications requiring a secure and easily accessible enclosure. It features a continuous hinge, screw-down clamps, and a durable steel construction.

Product Information

Standard Information

• Brand: HOFFMAN
• Manufacturer Part Number: A1412CHAL
• Country of Origin: MX - Mexico

Technical Specifications

• Application: For secure closure and can be used in a wide variety of applications
• Catalog Description (MFR): Continuous Hinge Enclosure Clamps CH Type 12, 14x12x6, Gray, Mild Steel
• Color: Gray
• Cover Type: Continuous Hinged/Screw Clamp
• Depth: 152 mm
• Finish: Polyester Powder Painted
• Height: 356 mm
• Label Description (MFR): CH Box 14.00x12.00x6.00
• Material: Steel
• Mounting Type: Wall
• NEMA Rating: 12
• Product Name: Continuous Hinge Enclosure
• Short Description: CH Box 14.00x12.00x6.00
• Standard: cUL Listed per CSA C22.2 File No. 94 File No. E27567, CSA File No. 42184, IEC 60529, UL 50/50E Listed File No. E27567, RoHS Compliant, REACH Compliant
• Type: Mild Steel Terminal and Junction Boxes
• Width: 305 mm
• Color Coding: ANSI 61
• Gauge: 14 and 16
• Size: 14.00x12.00x6.00 in
• Brand: nVent Hoffman
• Sub Brand: Hoffman
• Hinge Type: Continuous
• Latch: Screw-Down Clamps
