Henry Technologies SG-1010 Sight Glass 1-1/4 MPT

Product Description

The HENRY TECHNOLOGIES SG-1010 Sight Glass is designed for visual inspection of liquid refrigerant or oil levels in refrigeration and air conditioning systems. It is suitable for use with ammonia, HFC, and HCFC refrigerants and their associated oils, as well as other industrial fluids non-corrosive to steel and glass. This sight glass helps maintain optimal system performance and safety by ensuring proper fluid levels and flow.

• Features an NPT connection for secure installation.
• Equipped with a hermetically sealed viewing lens to prevent leaks.
• Designed with a high pressure rating for demanding applications.

Product Highlights

Provides unobstructed visual inspection of fluid levels and flow.

Product Information

Standard Information

• Brand: HENRY TECHNOLOGIES
• Manufacturer Part Number: SG-1010
• Country of Origin: US

Technical Specifications

• Maximum Working Pressure: 1000 PSI (68.9 bar)
• Allowable Operating Temperature: -20°F to +300°F (-29°C to +149°C)
• Connection Size: 1-1/4" Male Pipe Thread (MPT)
• Lens Type: Clear Lens
• Material: Plated steel body with a hermetically sealed fused glass lens
• Applications: Ideal for use with HCFC, HFC, and ammonia refrigerants, along with their associated oils
