Haydon A-316 Two Hole 45-Degree Open Angle Fitting

Product Description

The HAYDON A-316 is a two-hole, 45-degree open angle fitting designed for structural connections within H-STRUT® channel systems. This fitting is constructed from 1/4 inch thick steel, with a width of 1 5/8 inches. It features 9/16 inch diameter holes, spaced 1 7/8 inches on center and 13/16 inch from the end. Compatible with 1/2 inch channel nuts and bolts, it is suitable for various electrical and mechanical support applications. Multiple material and finish options are available to meet diverse environmental requirements.

• Provides structural connections with H-STRUT® channel
• Available in several materials and finishes
• Designed to be used with 1/2 inch channel nuts and bolts

Product Highlights

Durable 1/4 inch steel fitting for H-STRUT® channel, featuring two 9/16 inch holes and 45-degree open angle for secure connections.

Product Information

Standard Information

• Brand: HAYDON
• Manufacturer Part Number: A-316

Technical Specifications

• Steel Thickness: 1/4 inch
• Width: 1 5/8 inches
• Hole Diameter: 9/16 inch
• Hole Spacing (On Center): 1 7/8 inches
• Hole Spacing (From End): 13/16 inch
• Material Options: Hot Rolled Steel Sheet - ASTM A-1011, Cold Rolled Steel Sheet - ASTM A-1008, Stainless Steel-Type 304/316 - ASTM A-240, Aluminum Fitting - ASTM B-221
• Finish Options: Electro Galvanized - ASTM B-633, Hot Dipped Galvanized - ASTM A-123, Zinc Trivalent Chromium - ASTM B-633-85, Powder Coated Supr-Green - ASTM B-117, PVC Coating - Available Upon Request
