Harvey Tool 46030 Corner Rounding End Mill 2 Flute Carbide

Product Description

The HARVEY TOOL 46030 is a solid carbide corner rounding end mill designed to produce precise convex edge profiles on ferrous and non-ferrous workpieces. It features a 0.03 mm corner radius and a 1/8 inch mill diameter, making it well suited for fine edge-breaking and radius milling on small-footprint parts. The double-end configuration provides two usable cutting ends, extending tool life between change-outs. With a bright, uncoated finish and 2-flute geometry, this end mill is a reliable choice for shops running lighter finishing passes on a variety of materials. Licensed machinists and CNC operators are the primary users of this tool.

This end mill is intended for use in CNC machining centers and manual mills where a consistent, repeatable corner radius is required. The 1/8 inch shank diameter fits standard collets and end mill holders common in both production and job-shop environments. The 0.0470 inch tip diameter accommodates work in tight geometries. Typical applications include edge profiling on aluminum, steel, and plastic components where a small, uniform radius must be held to print.

Key Features

• 0.03 mm corner radius for fine, precise edge profiling
• Solid carbide construction for rigidity and wear resistance
• Double-end design provides two cutting ends per tool
• 2-flute geometry suited for lighter finishing passes
• Bright, uncoated finish compatible with a wide range of materials
• 1/8 inch shank diameter fits standard collet toolholders

Compatibility

Designed as an OEM-style corner rounding end mill for use in CNC machining centers and manual mills accepting a 1/8 inch shank diameter collet or end mill holder.

Installation Notes

Installation and tool changes should be performed by a qualified machinist with the spindle fully stopped and the machine in a locked-out, de-energized state. Seat the shank fully into the collet or toolholder and torque the retention nut according to the toolholder manufacturer specifications. Inspect the cutting edges for chips or damage before each use. Follow your facility safety protocols and applicable machine tool standards when setting tool offsets and running first-article cuts.
