Ham-let 3002303 Compression Male Run Tee 1/4 Inch Ss

Product Description

The HAM-LET 3002303 is a compression tube male run tee designed for high-pressure instrumentation and process piping systems. It connects two compression tube ends in line while providing a male NPT branch outlet, allowing a side takeoff without breaking the main run. Constructed from 316 stainless steel to ASTM A182, A213, A269, A276, and A479 standards, this fitting handles working pressures up to 8000 psi. It is a compact fitting at 1.98 inches overall length and weighs 0.25 pounds. Licensed plumbers, instrumentation technicians, and industrial pipefitters are the typical installers.

This fitting is suited for use in instrumentation tubing systems, process control lines, chemical and petrochemical applications, and any high-pressure service requiring a stainless steel inline tee with a threaded branch connection. The 1/4-inch thread size and Compression x MNPT x Compression end configuration make it a practical choice for connecting instrument tubing to panel-mounted components or valve manifolds. Its temperature range of -20 degrees F to 37 degrees F covers typical low-side service environments. This part is also cross-referenced as Swagelok part number SS-400-3-4TMT for compatibility reference.

Key Features

• 316 stainless steel construction meets ASTM A182, A213, A269, A276, and A479 material standards
• Rated to 8000 psi maximum working pressure for high-pressure instrumentation service
• Compression x MNPT x Compression end connections for inline run with threaded branch takeoff
• 1/4-inch male NPT thread standard for broad compatibility with instrumentation hardware
• Compact 1.98-inch overall length for tight panel or manifold installations
• Cross-referenced to Swagelok SS-400-3-4TMT for direct replacement sourcing

Compatibility

Cross-referenced as Swagelok part number SS-400-3-4TMT. Designed as an OEM-style replacement for 1/4-inch compression tube male run tee applications in instrumentation and process piping systems where 316 stainless steel and ASTM material compliance are required.

Installation Notes

Installation should be performed by a licensed pipefitter or instrumentation technician familiar with high-pressure compression fittings. Depressurize and isolate the line completely before disassembly or fitting installation. Compression fittings require proper tube preparation including squaring the tube end and verifying tube OD tolerance before insertion. Follow applicable codes such as ASME B31.3 for process piping when determining installation requirements for this fitting type.
