Guden 8000250612 Concealed Hinge 2.5 in Stainless Steel

Product Description

The GUDEN 8000250612 is a concealed hinge manufactured from grade 302/304 stainless steel, designed for enclosure panels, access doors, and equipment housings where a flush, low-profile pivot point is required. The hinge measures 2.5 inches in door leaf height and 1.25 inches in door leaf width, with a leaf thickness of 0.062 inches and a pin diameter of 0.12 inches. Six mounting holes are distributed across the leaf for secure fastening. Fabricators, enclosure builders, and maintenance technicians working with stainless steel cabinetry or industrial panels are the typical installers.

This hinge suits residential and commercial applications where a concealed pivot is preferred over a surface-mounted barrel hinge. Common install scenarios include electrical enclosures, control panel doors, HVAC equipment access panels, and light-duty cabinetry. The matching frame leaf height of 2.5 inches and frame leaf width of 1.25 inches allow symmetrical mortise or surface mounting on both the door and frame sides. RoHS compliance makes it suitable for projects with environmental material restrictions.

Key Features

• Grade 302/304 stainless steel construction for corrosion resistance in demanding environments
• Concealed design keeps hardware hidden when door is closed
• 2.5 inches door leaf height and 2.5 inches frame leaf height for symmetrical fitment
• 0.062 inches leaf thickness provides a low-profile footprint
• Six mounting holes for secure, distributed fastening load
• RoHS compliant materials

Compatibility

Designed as an OEM-style concealed hinge for light-duty panel doors, enclosure lids, and access doors requiring a 2.5 inch leaf height stainless steel pivot solution.

Installation Notes

Installation is typically performed by fabricators, millwork technicians, or maintenance electricians working on enclosure assemblies. De-energize all equipment before servicing any panel or door assembly. Pilot holes are recommended before driving fasteners to avoid distorting the thin stainless leaf. Verify fastener length does not penetrate through the panel material into live components.
