GRUVLOK ANVIL INTRNL 0390202067 Fig 7788 4 in Flange Adapter

Product Description

The GRUVLOK ANVIL INTRNL 390202067 is a FIG 7788 four-inch flange adapter. This adapter connects Class 125 or Class 150 flanged components directly to grooved piping systems. Its design offers an alternative to traditional Gruvlok flanges.

• Connects flanged components to grooved piping.
• Features a raised serrated face flange connection.
• Shorter overall length than standard flange x groove nipples.

Product Highlights

This flange adapter is ideal for applications requiring secure connections in grooved end pipes.

Product Information

Standard Information

• Brand: Gruvlok
• MPN: 390202067

Technical Specifications

• Fitting/Connector Type: Flange Adapter
• Nominal Size: Four inches
• End Style: Grooved x Flanged
• Finish: Rust inhibiting orange paint
• Material: Ductile iron
• Pressure Class: 125/150 lb
• Pressure Rating: 300 psi
• Series: FIG 7788
• Thickness: Three fourths inches
• Application: For grooved end pipes
• Standards and Approvals: ASTM A536
• Outside Diameter: Four and a half inches
