Gray Flex 06-gf-8_bag R-8 Flex Duct 6 in X 25 Ft

Product Description

The GRAY FLEX 06-gf-8_bag is a black insulated flexible air duct rated R-8.0, designed for residential and commercial HVAC distribution systems. The duct features an exclusive patented reinforced inner core that is fully airtight, preventing fiberglass from contacting the air stream. Fiberglass insulation is a minimum of 2 5/8 inches thick to deliver the R-8.0 thermal rating and help control condensation. A scuff-resistant black polyethylene jacket serves as the vapor barrier and is printed every 24 inches with certification labels, foot markers, size data, and performance data. HVAC technicians and sheet metal installers handle this product during system installations and retrofits.

This flexible duct is suited for residential and light commercial HVAC supply and return air distribution. It is compression packaged to less than 10 percent of its extended length, reducing storage space and jobsite handling time. The lightweight, flexible construction allows for quick routing around framing, joists, and other obstructions. Each bag contains one 6-inch-diameter duct section measuring 25 feet in extended length. The printed jacket data simplifies inspection and sign-off by code officials and AHJs.

Key Features

• R-8.0 insulation value with minimum 2 5/8 inches of fiberglass insulation thickness
• Exclusive patented airtight inner core eliminates fiberglass contact with conditioned air stream
• Black polyethylene vapor barrier jacket is scuff resistant and printed with certification, sizing, and performance data every 24 inches
• Tested and listed in accordance with UL 181 as a Class 1 air duct material
• Compression packaged to less than 10 percent of extended length for easier transport and storage
• Easier to cut than standard scrim-reinforced flex duct products

Compatibility

Listed under UL 181 as a Class 1 air duct material, making it approved for use in HVAC supply and return air distribution systems where Class 1 flexible duct is specified by code or design.

Installation Notes

Installation should be performed by a licensed HVAC technician or sheet metal contractor in accordance with SMACNA flexible duct installation standards and applicable local mechanical codes. Shut down the air handling unit and de-energize associated electrical components before connecting or modifying any duct sections. Fully extend the duct to its rated length before securing to avoid excessive pressure drop caused by compression. Secure each end with approved straps or clamps and seal with UL 181B-listed mastic or tape as required by code.

Technical Specifications

• Insulation Rating: R-8.0
• Duct Diameter: 6 inches
• Extended Length: 25 feet
• Minimum Insulation Thickness: 2 5/8 inches fiberglass
• Jacket Material: Black polyethylene vapor barrier
• Listing: UL 181 Class 1 Air Duct
• Packaging: Compression packaged to less than 10 percent of extended length

Standard Information

• Brand: GRAY FLEX
• Manufacturer Part Number: 06-gf-8_bag
