Goulds M30412 CentriPro pump motor 3 HP (4 in)

Product Description

Goulds M30412 is a 3 HP CentriPro pump motor rated 230 V, single-phase, 60 Hz for submersible pump applications. The three-wire, capacitor-start induction-run motor is designed for installation in 4 in wells and features stainless steel construction, a 17-4 PH splined shaft, and water-lubricated bearings. It includes a removable 100 in motor lead, built-in surge arrestors, and is CSA certified and tested to ANSI/NSF 61.

• 3 HP, single-phase, 230 V, 60 Hz; three-wire configuration.
• 4 in submersible CentriPro design with stainless steel casing and 17-4 PH splined shaft; water-lubricated with three-shoe Kingsbury thrust bearing.
• Capacitor-start induction-run motor with removable 100 in motor lead, built-in surge arrestors, and CSA certification; requires a control box (CB30412CR or CB30412MC).

Product Highlights

3 HP 230 V single-phase CentriPro submersible motor, 4 in, 3-wire capacitor-start design, stainless steel construction, CSA certified.

Product Information

Standard Information

• Brand: GOULDS
• Manufacturer Part Number: M30412
• Country of Origin: United States
