Goodman RX09RMVJU9A Single Zone Heat Pump Outdoor Unit

Product Description

The Goodman RX09RMVJU9A is a single-zone ductless heat pump outdoor unit rated at 9,000 BTU/h cooling capacity and 10,000 BTU/h heating capacity. Designed for wall-mount mini-split systems, it pairs with a compatible indoor air handler to deliver both cooling and heating from one compact unit. Operating on 208-230 volts at 60 Hz, single phase, it achieves a SEER of 18 and an EER of 11, making it a solid choice for efficiency-focused installations. The hermetically sealed swing compressor and electronic controls are engineered for reliable performance in residential and light commercial settings. Licensed HVAC technicians handle installation and commissioning.

This outdoor unit is intended for single-zone residential or commercial ductless applications where a wall-mount indoor head is specified. With an HSPF of 9.3, it provides year-round climate control without supplemental electric heat in moderate climates. The compact footprint - 26-9/16 inches wide, 21-5/8 inches tall, and 11-3/16 inches deep - suits installations where space around the outdoor unit is limited. Maximum vertical line set length is 65.63 feet, giving installers flexibility in positioning the outdoor unit relative to the indoor head.

Key Features

• 9,000 BTU/h cooling capacity and 10,000 BTU/h heating capacity in a single-zone configuration
• SEER 18 and EER 11 for above-code efficiency in residential installs
• HSPF 9.3 supports heating-dominant climates without auxiliary heat in mild conditions
• Hermetically sealed swing compressor with electronic control type for precise operation
• Pre-charged with R-410A refrigerant (0.21 oz) at the factory
• Outdoor sound level of 46 dBA / 50 dBA for low-noise operation near living spaces
• Max vertical line set length of 65.63 feet for flexible placement

Compatibility

Designed for use in Goodman single-zone ductless systems with a compatible wall-mount indoor head unit. Liquid line connection is 1/4 inch and suction line connection is 3/8 inch. Confirm indoor unit compatibility and line set sizing prior to installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding the appropriate EPA Section 608 certification for handling R-410A refrigerant. Shut off all power to the circuit before making electrical connections, and verify the supply voltage matches the unit rating of 208-230 volts, single phase, 60 Hz. Follow local mechanical and electrical codes for line set routing, outdoor unit pad or bracket mounting, and electrical disconnect requirements. Do not exceed the maximum vertical line set length of 65.63 feet stated by the manufacturer.
