GOODMAN CHPEA4830C3 Goodman CHPEA4830C3 4 Ton Horizontal Evaporator Coil

Product Description

The Goodman CHPEA4830C3 is a four-ton evaporator coil suitable for horizontal airflow applications. It has an all-aluminum construction with fins and grooved tubes. This product is designed for use with R-32 refrigerant and comes with a factory-installed thermal expansion valve. The galvanized, embossed cabinet features foil-faced insulation, which helps to reduce air leakage and cabinet condensation. A thermoplastic drain pan with secondary drain connections is included.

• All-aluminum evaporator coil design.
• Optimized for R-32 refrigerant.
• Factory-installed thermal expansion valve.

Product Highlights

This evaporator coil is ideal for residential and commercial HVAC systems where stable cooling is essential.

Product Information

Standard Information

• Brand: GOODMAN
• MPN: CHPEA4830C3

Technical Specifications

• Product Type: Evaporator Coil
• Tonnage: 4.0 Tons
• Cooling Capacity: 48000 BTU
• Refrigerant Type: R-32
• Casing: Cased
• Coil Type: A Coil
• Airflow Orientation: Horizontal
• TXV Installed: Yes
• Suction Connection Size: 7/8 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 21 Inches
• Product Height: 21 Inches
• Product Width: 30 Inches
• Product Depth: 21 Inches
• Product Weight: 63 Pounds
• Certifications: AHRI, ETL, ISO
• Parts Warranty: 10 Year Limited
