Goodman azv7sa4810 Split Heat Pump 17.5 SEER2 4 Ton

Product Description

The GOODMAN azv7sa4810 is a 4-ton, inverter-driven outdoor split heat pump designed for ducted residential and multi-family HVAC systems. It delivers a rated cooling capacity of 46,500 BTU/h and a rated heating capacity of 47,500 BTU/h at a 17.5 SEER2 efficiency rating. The variable-speed inverter compressor adjusts output continuously to match load demand, reducing short-cycling and improving comfort. Operating on R-32 refrigerant and rated at 208/230 volts, single phase, 60 Hz, this unit is side-discharge configured and produced in the United States. Licensed HVAC technicians handle installation and commissioning.

The azv7sa4810 is suited for ducted split-system installations in residential and multi-family applications where high seasonal efficiency and broad operating range are required. The unit maintains heating operation down to -10 degrees F ambient and cooling operation down to 0 degrees F ambient, making it a strong candidate for mixed-climate zones. DOE regional compliance is listed as All regions. It is ENERGY STAR certified and ISO certified, aligning with utility rebate program requirements in most markets.

Key Features

• Inverter compressor provides variable-capacity operation for improved efficiency and reduced temperature swings
• 17.5 SEER2 and HSPF2 of 8.8 meet high-efficiency thresholds across all DOE climate regions
• Heating operation range from -10 degrees F to 70 degrees F ambient supports cold-climate installations
• R-32 refrigerant with factory charge of 118 oz and pre-charged line set up to 15 feet
• Side-discharge airflow configuration for applications where top-discharge clearance is restricted
• ENERGY STAR certified and ISO certified; produced in the United States

Compatibility

The azv7sa4810 belongs to the Amana AZV7S series and is a non-communicating outdoor unit for use with compatible ducted indoor coil and air handler combinations. Referenced component accessories include part numbers 130-DK-008, DACA-WB-3, DQ-P-16-100, DSEN-HAQA, KEH3P573567, KPS00601, KPS00602, KPS00603, KPS00604, and KPW5G112 as listed by the manufacturer.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA Section 608 certification due to the use of R-32 refrigerant, which is an A2L mildly flammable refrigerant requiring specific handling procedures and compatible tooling. Shut off all power at the disconnect before making electrical or refrigerant connections. Minimum circuit ampacity is 37.5 A with a maximum overcurrent protection of 40 A; size the disconnect and wire gauge accordingly per NEC requirements. Line set connections use a 3/8-inch liquid line and a 3/4-inch gas line, with suction valve O.D. of 7/8 inch; maximum standard line set length is 100 feet with a maximum vertical run of 90 feet.

Technical Specifications

• Cooling Capacity (Rated): 46,500 BTU/h
• Heating Capacity (Rated): 47,500 BTU/h
• Heating Capacity (Nominal): 48,000 BTU/h
• Tonnage: 4 tons
• SEER2: 17.5
• HSPF2: 8.8
• EER2: 10
• COP at 47 degrees F: 3.3
• Voltage: 208/230 volts, 1-phase, 60 Hz
• Rated Load Amps: 30 A
• Minimum Circuit Amps: 37.5 A
• Max Overcurrent Protection: 40 A
• Compressor Type: Inverter (variable-speed)
• Refrigerant: R-32
• Factory Refrigerant Charge: 118 oz
• Pre-Charged Line Length: 15 feet
• Max Line Set Length: 100 feet
• Max Vertical Line Set: 90 feet
• Liquid Line Size: 3/8 inch
• Gas Line Size: 3/4 inch
• Suction Valve O.D.: 7/8 inch
• Cooling Operation Range: 0 degrees F to 115 degrees F ambient
• Heating Operation Range: -10 degrees F to 70 degrees F ambient
• Unit Height: 39 inches
• Unit Width: 37 inches
• Unit Depth: 12.625 inches
• Unit Weight: 179 pounds
• Sound Pressure (Cooling High): 71 dBA
• Installation Configuration: Side Discharge
• Communication Type: Non-Communicating
• DOE Regional Compliance: All regions
• ENERGY STAR Certified: Yes
• ISO Certified: Yes
• Country of Origin: United States
• Residential Parts Warranty (Registered): 10 years all parts; 10 years compressor
• Residential Unit Replacement Warranty (Registered): 10 years compressor
• Standard Parts Warranty: 5 years all parts

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv7sa4810
