Goodman azv7sa4210 Split Heat Pump 3.5 Ton 17.5 SEER2

Product Description

The GOODMAN azv7sa4210 is a 3.5-ton inverter-driven split heat pump outdoor unit rated at 17.5 SEER2 and designed for ducted residential and light-commercial applications. It operates on R-32 refrigerant and uses a variable-speed inverter compressor to match heating and cooling output to actual load demand, reducing short-cycling and improving efficiency across a wide range of conditions. The unit delivers 41,000 BTU/h rated cooling capacity and 41,000 BTU/h rated heating capacity, with a COP of 3.3 at standard heating test conditions. Side-discharge airflow suits installations where top discharge is impractical. It is produced in the United States and carries ENERGY STAR certification.

This unit is intended for ducted split-system installations in residential, multi-family, and light-commercial settings. The side-discharge cabinet configuration is suited for ground-level pad mounts in tight equipment yards or courtyard installations. The inverter compressor stage count allows operation across a wide ambient range: cooling from 0 degrees F to 115 degrees F ambient and heating from -10 degrees F to 70 degrees F ambient, making it viable in cold-climate zones. DOE regional compliance is listed as All regions. The non-communicating control interface allows pairing with standard 24-volt thermostats and air handlers without a proprietary bus.

Key Features

• Inverter-driven variable-speed compressor for part-load efficiency and reduced short-cycling
• 17.5 SEER2 and HSPF2 of 8.8 at standard test conditions, ENERGY STAR certified
• R-32 refrigerant with factory charge of 118 oz and pre-charged line length of 15 feet
• Side-discharge cabinet, 39 inches tall, for flexible pad or slab installation
• Heating operation down to -10 degrees F ambient for cold-climate suitability
• Non-communicating design compatible with standard 24-volt controls
• Produced in the United States, ISO certified

Compatibility

The azv7sa4210 is part of the Amana AZV7S series and is designed for use in ducted split-system configurations. Referenced accessory and component part numbers from the manufacturer include 130-DK-008, DACA-WB-3, DQ-P-16-100, DSEN-HAQA, KEH3P573567, KPS00601, KPS00602, KPS00603, KPS00604, and KPW5G112. No additional compatible indoor unit model numbers were specified in the product data.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA Section 608 certification, as R-32 is an A2L mildly flammable refrigerant requiring specific handling procedures and leak-detection practices per current ASHRAE and local codes. Disconnect and lock out all electrical power before servicing the unit. Observe minimum circuit ampacity of 37.5 amps and maximum overcurrent protection of 40 amps when sizing disconnect and wiring per NEC requirements. Verify line set length does not exceed 100 feet total or 90 feet vertical per manufacturer guidelines before commissioning.

Technical Specifications

• Cooling Capacity (Rated): 41,000 BTU/h
• Heating Capacity (Rated): 41,000 BTU/h
• Heating Capacity (Nominal): 42,000 BTU/h
• Tonnage: 3.5 tons
• SEER2: 17.5
• HSPF2: 8.8
• EER2: 10
• COP at 47 degrees F: 3.3
• Compressor Type: Inverter (variable-speed)
• Refrigerant: R-32
• Factory Refrigerant Charge: 118 oz
• Power Voltage: 208/230 volts, 1-phase, 60 Hz
• Rated Load Amps: 30 amps
• Minimum Circuit Amps: 37.5 amps
• Max Overcurrent Protection: 40 amps
• Sound Pressure (Cooling High): 71 dBA
• Cooling Ambient Range: 0 degrees F to 115 degrees F
• Heating Ambient Range: -10 degrees F to 70 degrees F
• Unit Height: 39 inches
• Unit Width: 37 inches
• Unit Depth: 12.625 inches
• Weight: 179 pounds
• Discharge Configuration: Side Discharge
• Installation Type: Ducted
• Liquid Line Connection (OD): 3/8 inch
• Gas Line Connection (OD): 3/4 inch
• Suction Valve (OD): 7/8 inch
• Pre-Charged Line Length: 15 feet
• Max Standard Line Set Length: 100 feet
• Max Vertical Line Set: 90 feet
• DOE Regional Compliance: All regions
• ENERGY STAR Certified: Yes
• ISO Certified: Yes
• Country of Origin: United States
• Residential Registered Parts Warranty: 10 years all parts, 10 years compressor
• Residential Registered Unit Replacement Warranty: 10 years compressor
• Standard Parts Warranty (Residential): 5 years all parts
• Commercial Parts Warranty: 5 years all parts

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv7sa4210
