Goodman azv6sa4810 Split Heat Pump 16.2 SEER2 4 Ton

Product Description

The GOODMAN azv6sa4810 is a 4-ton, single-phase outdoor split heat pump designed for ducted residential and commercial HVAC systems. Rated at 16.2 SEER2 and 8.2 HSPF2, it uses an inverter-driven variable-speed compressor and R-32 refrigerant for efficient heating and cooling across a wide ambient range. Rated cooling and heating capacity both sit at 45,500 BTU/h. Electrical requirements are 208/230 volts at 60 Hz, with a minimum circuit ampacity of 31.8 amps and maximum overcurrent protection of 35 amps. The unit features side-discharge airflow and is produced in the United States.

This unit is suited for ducted residential, multi-family, and light commercial split-system installations where inverter-compressor technology is specified. The side-discharge configuration supports installations where top-discharge clearance is restricted. Operating temperatures span from -10 degrees F to 70 degrees F for heating and from 0 degrees F to 115 degrees F for cooling, making it functional in a broad range of climates. Installation is non-communicating, allowing it to pair with standard non-proprietary air handlers and coils without a communicating control system. All DOE regional efficiency compliance zones are satisfied.

Key Features

• Inverter-driven variable-speed compressor for modulating capacity and reduced cycling
• 16.2 SEER2 cooling efficiency and 8.2 HSPF2 heating efficiency under HSVTC conditions
• R-32 refrigerant with factory-standard charge of 100 oz and pre-charged line length of 15 feet
• Side-discharge airflow configuration for space-constrained outdoor installations
• Operational heating range down to -10 degrees F ambient for cold-climate applications
• Produced in the United States and meets DOE regional compliance for all zones
• Registered residential warranty includes 10-year parts and 10-year compressor unit replacement coverage

Compatibility

The azv6sa4810 is a non-communicating outdoor unit in the Amana AZV6SA series, designed to match with compatible ducted air handlers and indoor coils. Referenced component accessories include 130-DK-008, DACA-WB-3, DQ-P-16-100, DSEN-HAQA, KEH3P573567, KPS00601, KPS00602, KPS00603, KPS00604, and KPW5G112. Consult the unit installation manual and Amana product matching guides to verify approved indoor unit pairings before installation.

Installation Notes

Installation should be performed by a licensed HVAC technician holding an EPA Section 608 certification, as R-32 is an A2L mildly flammable refrigerant requiring specific handling procedures and tools. Disconnect and lock out all electrical power before servicing or connecting refrigerant lines. Maximum line set length is 100 feet horizontal and 90 feet vertical; do not exceed factory line set specifications. Follow local mechanical and electrical codes, including NEC requirements for disconnect sizing and overcurrent protection rated at 35 amps maximum.

Technical Specifications

• Cooling Capacity (Rated): 45,500 BTU/h
• Heating Capacity (Rated): 45,500 BTU/h
• Heating Capacity (Nominal): 48,000 BTU/h
• Tonnage: 4 tons
• SEER2: 16.2
• SEER2 (HSVTC): 17
• HSPF2: 8.2
• EER2 (HSVTC): 9
• COP47 (HSVTC): 3.3
• Power Voltage: 208/230 volts
• Power Phase: Single phase
• Power Frequency: 60 Hz
• Minimum Circuit Amps: 31.8 amps
• Rated Load Amps: 25.4 amps
• Max Overcurrent Protection: 35 amps
• Compressor Type: Inverter (variable speed)
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 100 oz
• Pre-Charged Line Length: 15 feet
• Max Line Set Length (Horizontal): 100 feet
• Max Line Set Length (Vertical): 90 feet
• Liquid Line Size: 3/8 inches
• Gas/Suction Line Size: 7/8 inches
• Cooling Operating Range: 0 degrees F to 115 degrees F
• Heating Operating Range: -10 degrees F to 70 degrees F
• Sound Pressure (High, Cooling): 72 dBA
• Unit Height: 39 inches
• Unit Width: 37 inches
• Unit Depth: 12.625 inches
• Unit Weight: 168 pounds
• Installation Configuration: Side Discharge
• Installation Type: Ducted
• Communication Type: Non-Communicating
• DOE Regional Compliance: All regions
• Country of Origin: United States
• Residential Parts Warranty (Registered): 10 years all parts
• Residential Compressor Warranty (Registered): 10 years unit replacement
• Standard Parts Warranty (Residential): 5 years all parts
• Commercial Parts Warranty: 5 years all parts

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv6sa4810
