Goodman azv6sa3010 Split Heat Pump 2.5 Ton 16.2 SEER2

Product Description

The GOODMAN azv6sa3010 is a 2.5-ton inverter-driven outdoor split heat pump designed for ducted residential and light-commercial HVAC systems. Rated at 16.2 SEER2 and 8.5 HSPF2, it delivers 28,400 BTU/h cooling and 28,800 BTU/h heating under standard rated conditions. The unit runs on R-32 refrigerant, operates on 208/230 volts single-phase 60 Hz power, and features a side-discharge configuration. The inverter-driven variable-speed compressor modulates capacity to match load, reducing runtime cycling and improving efficiency across a wide range of ambient conditions. Licensed HVAC technicians perform installation and commissioning.

This unit is suited for ducted split-system installations in residential and multi-family applications where high-efficiency performance is required without a communicating thermostat or communicating controls. The non-communicating design allows pairing with standard low-voltage thermostat wiring. Side-discharge airflow suits ground-level pad installations where top-discharge clearances are restricted. The operating range extends from -10 degrees F to 70 degrees F in heating mode and from 0 degrees F to 115 degrees F in cooling mode, making it viable in a broad range of North American climates. DOE regional compliance covers all regions.

Key Features

• Inverter-driven variable-speed compressor for efficient part-load operation
• 16.2 SEER2 cooling efficiency and 8.5 HSPF2 heating efficiency
• R-32 refrigerant with factory charge of 76 oz and pre-charged line set support up to 15 feet
• Side-discharge configuration for flexible ground-level placement
• Wide heating operating range down to -10 degrees F ambient
• Non-communicating control interface compatible with standard low-voltage thermostats
• ISO certified manufacturing; meets DOE compliance for all regions

Compatibility

Designed as an OEM outdoor split heat pump unit within the Amana AZV6SA series for ducted non-communicating split heat pump systems. No specific indoor unit model numbers were provided in the product data; consult manufacturer matchup tables to confirm approved indoor coil or air handler pairings before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding EPA 608 certification for handling refrigerants. Disconnect and lock out all electrical power before servicing or making electrical connections, and shut off the disconnect box within sight of the unit per NEC requirements. Verify line set sizing against manufacturer guidelines: liquid line 3/8 inch, suction line 7/8 inch outside diameter; maximum standard line set length is 100 feet with a maximum vertical rise of 90 feet. Do not exceed the 25-amp maximum overcurrent protection rating when sizing the disconnect and breaker.

Technical Specifications

• Tonnage: 2.5 tons
• Cooling Capacity (Rated): 28,400 BTU/h
• Heating Capacity (Rated): 28,800 BTU/h
• Heating Capacity (Nominal): 30,000 BTU/h
• SEER2: 16.2
• SEER2 (HSVTC): 17.5
• HSPF2: 8.5
• EER2 (HSVTC): 10
• COP47 (HSVTC): 3.3
• Power Voltage: 208/230 volts
• Power Phase: 1 phase
• Power Frequency: 60 Hz
• Rated Load Amps: 17.6 A
• Minimum Circuit Amps: 22.4 A
• Maximum Overcurrent Protection: 25 A
• Compressor Type: Inverter variable-speed
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 76 oz
• Pre-Charged Line Length: 15 feet
• Max Line Set Length: 100 feet
• Max Vertical Line Set: 90 feet
• Liquid Line Size: 3/8 inch
• Gas Line Size: 7/8 inch
• Suction Valve OD: 7/8 inch
• Installation Configuration: Side Discharge
• Installation Type: Ducted
• Communication Type: Non-Communicating
• Cooling Operating Range: 0 degrees F to 115 degrees F
• Heating Operating Range: -10 degrees F to 70 degrees F
• Sound Pressure (Cooling High): 66 dBA
• Motor Speed Type: Multi-Speed
• Unit Height: 27.375 inches
• Unit Width: 36.625 inches
• Unit Depth: 13.75 inches
• Unit Weight: 132 pounds
• DOE Regional Compliance: All regions
• ISO Certified: Yes
• Country of Origin: Mexico
• Standard Parts Warranty (Residential): 5 years all parts
• Registered Parts Warranty (Residential): 10 years all parts; 10 years compressor
• Registered Unit Replacement Warranty (Residential): 10 years compressor
• Standard Parts Warranty (Commercial): 5 years all parts
• Registered Parts Warranty (Commercial): 5 years all parts
• Standard Parts Warranty (Multi-Family): 5 years all parts
• Registered Parts Warranty (Multi-Family): 10 years all parts

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: azv6sa3010
