Goodman axv6ss2410 Split Ac 2 Ton 16.2 SEER2 Side Discharge

Product Description

The GOODMAN axv6ss2410 is a 2-ton, 16.2 SEER2 inverter-driven outdoor split air conditioner designed for residential and multi-family cooling applications. Operating on R-32 refrigerant and powered by a variable-speed inverter compressor, this side-discharge unit delivers a rated cooling capacity of 23,200 BTU/h at standard ARI conditions. The 208/230-volt, single-phase unit draws a maximum of 13.3 amps at rated conditions with a minimum circuit ampacity of 16.8 amps. It carries DOE regional compliance for both Southeast and North installations. Licensed HVAC technicians handle installation, refrigerant handling, and startup commissioning for this class of equipment.

The axv6ss2410 is suited for residential split-system installations and multi-family projects where inverter-based efficiency and a compact side-discharge footprint are required. The unit is rated for operation in ambient temperatures ranging from 0 degrees F to 115 degrees F, making it viable across a broad range of climate conditions. Communication features are factory-enabled and designed to work with the Amana Brand smart thermostat. The AXV6SS series is manufactured in Mexico. Related system accessories listed by the manufacturer include components 130-DK-006, DACA-WB-3, and KPW5G112.

Key Features

• Inverter compressor delivers variable-capacity output for precise temperature control and reduced cycling
• 16.2 SEER2 and 10.2 EER2 efficiency ratings meet DOE compliance for Southeast and North regions
• R-32 refrigerant charge factory-installed at 74 oz with a pre-charged line length of 15 ft
• Side-discharge airflow configuration simplifies placement in tight or restricted installations
• Multi-speed fan motor supports quiet operation at 64 dBA sound pressure during cooling
• Integrated communication capability pairs with the Amana Brand smart thermostat for system-level control

Compatibility

Designed for use as the outdoor unit in a matched split-system configuration within the Amana AXV6SS series. Communication features are compatible with the Amana Brand smart thermostat. Consult manufacturer submittal documentation to confirm matched indoor coil and air handler selections before installation.

Installation Notes

Installation must be performed by an EPA Section 608-certified HVAC technician due to the R-32 refrigerant used in this unit. De-energize the disconnect and verify zero voltage at the unit before making any electrical or refrigerant connections. Suction and liquid line sizes are 3/4 inch and 3/8 inch respectively; do not exceed a maximum line set length of 100 ft horizontal or 90 ft vertical. Follow local mechanical and electrical codes, including NEC requirements for minimum circuit ampacity and overcurrent protection sizing, when sizing the disconnect and branch circuit wiring.

Technical Specifications

• Cooling Capacity (Rated): 23,200 BTU/h
• Tonnage: 2 tons
• SEER2: 16.2
• SEER2 (HSVTC): 18
• EER2 (HSVTC): 10.2
• Compressor Type: Inverter
• Power Voltage: 208/230 volts
• Power Phase: Single phase
• Power Frequency: 60 Hz
• Fan/Compressor Drive Input: 13.3 amps
• Minimum Circuit Amps: 16.8 amps
• Max Overcurrent Protection: 20 amps
• Refrigerant Type: R-32
• Factory Refrigerant Charge: 74 oz
• Pre-Charged Line Length: 15 ft
• Max Line Set Length (Horizontal): 100 ft
• Max Line Set Length (Vertical): 90 ft
• Pipe Size Liquid: 3/8 inch
• Pipe Size Gas / Suction Valve O.D.: 3/4 inch
• Installation Configuration: Side Discharge
• Motor Speed Type: Multi-Speed
• Sound Pressure (Cooling High): 64 dBA
• Cooling Operation Range: 0 degrees F to 115 degrees F
• Unit Width: 36.625 inches
• Unit Height: 27.375 inches
• Unit Depth: 13.75 inches
• Weight: 119 pounds
• DOE Regional Compliance: Southeast and North
• Residential Parts Warranty (Registered): 10 years all parts; 10 years compressor unit replacement
• Residential Parts Warranty (Standard): 5 years all parts
• Commercial Parts Warranty: 5 years all parts
• Multi-Family Parts Warranty (Registered): 10 years all parts
• Country of Origin: Mexico

Standard Information

• Brand: GOODMAN
• Manufacturer Part Number: axv6ss2410
