Gits Manufacturing Co. 04402 BW-50 Liquid Level Gauge

Product Description

The Gits Manufacturing Co. 04402 is a BW-50 Liquid Level Gauge designed for precise liquid measurements. This gauge features a glass window and is built to withstand high pressures, making it ideal for various applications. It is suitable for use in settings that require reliable monitoring of liquid levels.

• Durable steel construction with nickel plating
• Thread size of three-fourths inches
• Leak-tight design ensures no spills or wastage

Product Highlights

This liquid level gauge provides an easy-to-read glass window and is engineered for high-pressure environments.

Product Information

Standard Information

• Brand: Gits Manufacturing Co.
• Part Number: 101981349

Technical Specifications

• Thread Type: NPT
• Thread Size: 3/4
• Thread Lead: 5/8 inches
• Window Diameter: 3/4 inches
• Body Length: 15/16 inches
• Material: Steel, Nickel Plated
• Pressure Rating: 3,000 psi
• Assembly Clearance: 1 5/16 inches
• Threads per Inch: 14
• Weight: 0.114 lb
