Gibraltar SKNL-0-G Knob Handle Plunger 10-32 Thread

Product Description

The GIBRALTAR SKNL-0-G is a non-locking knob handle plunger with a 10-32 thread size and a knurled knob design. It is used to index, position, or lock moving components in light-duty mechanical assemblies. The plunger body is machined from stainless steel for corrosion resistance in demanding environments. Key dimensions include a body length of 0.46 inches, a thread length of 0.4 inches, and a maximum plunger diameter of 0.104 inches. Spring force ranges from an initial end force of 0.5 pounds to a final end force of 3 pounds. Machinists, maintenance technicians, and equipment assemblers install this type of hardware in panel, fixture, and jig applications.

This plunger is suited for light industrial and mechanical assembly applications where a hand-adjustable indexing or positioning point is needed. The knurled knob allows tool-free operation during setup or adjustment. With a plunger projection of 0.094 inches and a non-locking plunger type, it is appropriate for applications that require repeatable positioning without a permanent lock. Typical use cases include machine tool fixtures, control panels, enclosures, and fabricated assemblies where a 10-32 threaded hole is already present.

Key Features

• Non-locking plunger type allows quick repositioning without tools
• Knurled knob handle enables hand-tightening and adjustment
• 10-32 thread size with 0.4 inch thread length for standard tapped holes
• Stainless steel construction resists corrosion in wet or harsh environments
• Spring force range of 0.5 pounds initial to 3 pounds final end force
• Plunger projection of 0.094 inches for low-profile indexing applications

Compatibility

Designed as an OEM-style replacement or standard component for mechanical assemblies requiring a 10-32 threaded non-locking knob plunger.

Installation Notes

Installation is performed by threading the SKNL-0-G into a pre-tapped 10-32 hole by hand or with a wrench applied to the head shoulder. Ensure the mating assembly is de-energized or at rest before installing or adjusting plunger hardware in live machinery. Do not overtighten, as stainless steel fasteners are susceptible to galling in threaded holes. Verify plunger projection and spring force requirements are compatible with the indexed feature before final installation.
