Gibraltar G10-2310 Pointer Control Knob

Product Description

The GIBRALTAR G10-2310 is a pointer-style control knob designed for use with panel-mounted controls, switches, and rotary actuators in light industrial and commercial equipment. The knob measures 1-3/16 inches in diameter and 1/2 inches in height, with a 1/4 x 7/16 inches bore hole sized to accept a standard D-shaft or round shaft with a set screw. The set screw sits 7/32 inches from the bottom of the bore, and the insert height is 7/16 inches. The PH-style profile provides a clear directional indicator, making it suitable for panel controls where position reference matters. Electricians, HVAC technicians, and equipment maintenance professionals install this type of knob during control panel assembly or replacement service.

This pointer control knob fits applications where a visual reference to rotary position is required on a panel-mounted potentiometer, rotary switch, or similar actuator. Common install scenarios include HVAC control panels, industrial enclosures, and commercial equipment consoles where a technician needs a positive positional indicator. The bore and set screw configuration allow secure mounting to standard shaft diameters used across a wide range of control components.

Key Features

• Pointer (PH) style profile provides a clear directional reference on rotary controls
• 1/4 x 7/16 inches bore accommodates standard D-shaft and round shaft configurations
• Set screw positioned 7/32 inches from bore bottom for secure shaft engagement
• Compact form factor at 1-3/16 inches diameter and 1/2 inches height suits tight panel layouts
• 7/16 inches insert height provides stable shaft grip depth

Compatibility

Designed as an OEM-style replacement or new-installation pointer control knob for panel-mounted rotary controls accepting a 1/4-inch shaft with a 1/4 x 7/16 inches bore opening.

Installation Notes

Installation is performed by electricians or equipment technicians during control panel assembly or maintenance. Power down and de-energize the control panel completely before removing or installing control knobs to avoid accidental actuation. Align the knob bore with the shaft and tighten the set screw securely to prevent slippage during operation. Follow applicable NEC guidelines and equipment manufacturer procedures when servicing control panels.
