Gibraltar G10-1400 Pointer Control Knob 27/32 in

Product Description

The GIBRALTAR G10-1400 is a pointer-style control knob designed for use on shafts requiring a 1/4 x 11/32 inch hole fit. The knob measures 27/32 inches in diameter and 13/32 inches in height, with an 11/32 inch hole depth. An 8-32 set screw secures the knob to the shaft, with a set screw to bottom dimension of 3/16 inches. This hardware component is installed by HVAC technicians, electricians, and equipment service professionals on control panels, thermostats, potentiometers, and similar instrumentation requiring precise, repeatable pointer positioning.

The G10-1400 pointer control knob is suited for residential and light commercial control panel applications. It fits standard D-shaft and round shaft configurations within the specified hole dimensions. Typical installations include HVAC zone controllers, fan speed selectors, and other panel-mount control devices where a visual indicator is needed for setting position. This knob is sold individually per package, with a minimum order quantity of 10 units.

Key Features

• Pointer style (PH) provides clear visual position indication on control panels
• 27/32 inch diameter with 13/32 inch height for compact panel fitment
• 1/4 x 11/32 inch hole size accommodates standard shaft profiles
• 11/32 inch hole depth and 8-32 set screw for secure shaft retention
• Set screw to bottom dimension of 3/16 inches for precise seating

Compatibility

Designed as an OEM-style replacement or new-installation knob for control panels and instrumentation equipment accepting a 1/4 x 11/32 inch shaft with 8-32 set screw mounting.

Installation Notes

Installation is performed by qualified HVAC technicians, electricians, or instrumentation technicians. De-energize the equipment and confirm the circuit is isolated before replacing or installing any panel control components. Secure the knob onto the shaft before tightening the 8-32 set screw to prevent shaft or knob damage. Verify shaft alignment with the pointer indicator before final tightening.
