Gibraltar G-02FC40832 Symmetrical Hex Clamp 8-32 10-pack

Product Description

The GIBRALTAR G-02FC40832 is a symmetrical hex clamp designed for secure mechanical fastening applications requiring precise stud thread engagement. This clamp features a 5/16 inch hex size with an 8-32 stud thread, making it a standard choice for panel mounting, electronic enclosures, and light structural assemblies. The hex clamp style allows installation with common hex drivers or wrenches, and the symmetrical profile simplifies orientation during assembly. The hex height measures 0.11 inches with a thread length of approximately 0.36 inches. Each package contains 10 clamps and weighs 1 pound. These are typically installed by electricians, mechanical assemblers, and enclosure fabricators working in panel and cabinet applications.

This clamp is suited for use in electrical panel fabrication, control enclosures, HVAC equipment cabinets, and general mechanical assemblies where 8-32 threaded stud connections are specified. The symmetrical hex design provides consistent torque distribution and allows the fastener to be installed from either end without repositioning. The compact hex height of 0.11 inches keeps the installed profile low, which is useful in tight enclosure spaces. This part ships in a pack of 10, making it practical for service vans and stocking at the bench level.

Key Features

• Symmetrical hex profile allows installation from either end without reorientation
• 5/16 inch hex size compatible with standard hex drivers and wrenches
• 8-32 stud thread for engagement with common panel and enclosure studs
• Low-profile hex height of 0.11 inches suits tight enclosure assemblies
• Thread length of 0.36 inches provides reliable stud engagement depth
• Packaged in quantities of 10 for bench-stock and field replenishment

Compatibility

Designed as an OEM-style fastening component for mechanical and electrical assemblies using 8-32 threaded studs in panel, enclosure, and cabinet fabrication applications.

Installation Notes

Installation is performed by qualified electricians or mechanical assemblers working on panel and enclosure assemblies. Ensure the mating stud thread is clean and free of debris before engagement. Use an appropriately sized hex driver or wrench matching the 5/16 inch hex to achieve proper seating. Follow applicable NEC guidelines and enclosure manufacturer specifications for fastener torque and assembly procedures.
