Gibraltar DTS-5-G Tapped Pivotal Leveling Mount 2400 Lb

Product Description

The GIBRALTAR DTS-5-G is a tapped pivotal leveling mount designed to provide stable, adjustable support for industrial equipment and machinery. It features a 4-inch base diameter steel pad and a steel stud with a 1-8 thread size, allowing secure installation into tapped mounting holes. With a load capacity of 2,400 pounds, this mount is built for heavy-duty applications where solid, level support is critical. The pivotal pad design compensates for minor floor irregularities, keeping equipment properly aligned without shimming. Maintenance technicians and millwrights typically install this type of hardware during equipment positioning and commissioning.

This leveling mount suits a wide range of industrial and commercial applications including machine bases, conveyors, fabrication equipment, compressors, and other floor-mounted machinery. Its tapped design accepts a threaded stud for straightforward integration into equipment frames. The 4-inch base distributes load across the floor surface, making it appropriate for both concrete and finished flooring when proper load ratings are observed. The 1-3/8-inch hex allows for easy adjustment with standard wrenches during leveling operations.

Key Features

• 2,400 lb load capacity for heavy-duty equipment support
• Tapped pivotal pad design compensates for uneven floor surfaces
• 4-inch base diameter distributes load and improves stability
• Steel pad and steel stud construction for durability in industrial environments
• 1-8 thread size for reliable engagement with compatible tapped mounts
• 1-3/8-inch hex for adjustment with standard wrenches

Compatibility

Designed as an OEM-style leveling mount for industrial and commercial machinery requiring tapped pivotal adjustment with a 1-8 thread size and 4-inch base diameter footprint.

Installation Notes

Installation is typically performed by millwrights, mechanical contractors, or maintenance technicians. Before installation, ensure the equipment is de-energized, depressurized, and safely supported. Thread engagement should be verified to be sufficient for the rated load before the equipment is set down on the mounts. Use the 1-3/8-inch hex to adjust mount height and achieve level positioning, then secure lockouts or jam nuts per the equipment manufacturer's instructions.
