Gibraltar BSMNYLC36-G Studded Pivotal Leveling Mount

Product Description

The GIBRALTAR BSMNYLC36-G is a studded pivotal leveling mount designed for industrial and commercial equipment positioning applications. It features an M16 bolt thread, a stainless steel pad, and a stainless steel stud, providing corrosion resistance and reliable load-bearing performance. The mount accepts a load capacity of 2,270 kilograms and sits on a base diameter of 76 millimeters. The overall length is 181 millimeters. This type of leveling mount is typically installed by millwrights, maintenance technicians, or mechanical contractors who need precise floor-level adjustment under machinery, frames, or equipment bases.

Studded pivotal leveling mounts are used in light industrial, commercial, and manufacturing environments where equipment must be leveled on uneven or rough floor surfaces. The pivoting pad design accommodates slight floor irregularities without introducing stress into the stud or base. This mount is suited for stationary machinery, conveyor frames, workbenches, and similar equipment installations where stable, adjustable support is required. The stainless steel construction makes it appropriate for environments where moisture or washdown conditions are a concern.

Key Features

• M16 bolt thread for compatibility with standard metric mounting hardware
• 2,270 kilogram load capacity for demanding industrial support applications
• 76 millimeter base diameter provides a stable footprint
• Stainless steel pad and stud for corrosion resistance in wet or harsh environments
• Pivoting pad design compensates for minor floor surface irregularities
• 181 millimeter overall length allows for meaningful height adjustment range

Compatibility

Designed as a direct-install leveling mount for equipment and machinery frames using M16 metric threaded mounting points in industrial and commercial applications.

Installation Notes

Installation is typically performed by a millwright or mechanical technician using standard metric hand tools. The equipment or frame must be de-energized and safely supported before adjusting or replacing leveling mounts. Thread engagement should be sufficient to support the rated load without relying on only a few thread turns. Follow applicable facility safety procedures and equipment manufacturer guidelines when positioning or leveling machinery.
