Gibraltar BNYLC3-T-G Tapped Pivotal Leveling Mount 5/8-11

Product Description

The GIBRALTAR BNYLC3-T-G is a tapped pivotal leveling mount designed to provide stable, adjustable support for industrial machinery, equipment bases, and fabricated frames. It accepts a 5/8-11 threaded stud and features a pivoting steel pad that self-adjusts to uneven floor surfaces, maintaining full contact and load distribution without shimming. Rated at 5,000 lb load capacity, this mount is built from 1214-grade steel for both the stud and pad. The 3-inch base diameter spreads the load effectively across the mounting surface. Licensed HVAC technicians, millwrights, pipefitters, and industrial maintenance professionals commonly specify this type of mount during equipment installation and leveling.

This leveling mount suits a wide range of applications including HVAC unit bases, compressor skids, pump frames, electrical enclosures, and light industrial machinery. The tapped pivotal style allows the installer to thread the stud into a tapped hole in the equipment base, making it a direct OEM-style fit for equipment that accepts 5/8-11 threaded leveling feet. It is appropriate for both new installations and replacement of worn or damaged leveling feet in industrial and commercial environments.

Key Features

• 5,000 lb static load capacity for heavy industrial and commercial equipment support
• Pivoting steel pad self-levels on uneven floor surfaces without shimming
• 5/8-11 tapped thread for direct installation into equipment base tapped holes
• 3-inch base diameter distributes load across the floor contact area
• 1214-grade steel construction for stud and pad
• Compact overall length of 1-5/8 inches for low-profile installations

Compatibility

Designed as an OEM-style replacement or new-installation leveling mount for industrial and commercial equipment with 5/8-11 tapped base holes requiring pivotal leveling feet.

Installation Notes

Installation is typically performed by millwrights, pipefitters, or industrial maintenance technicians during equipment setting or base leveling. Power down and de-energize any connected equipment before adjusting leveling mounts under load-bearing bases. Thread the stud fully into the tapped hole in the equipment base before adjusting height, and verify the pad seats flush on the floor surface before applying full load. Always confirm the floor surface load rating meets or exceeds the combined equipment weight before finalizing leveling.
