Gibraltar 26395 5 Fixed Shoulder Eye Bolt 1400 Lb 3/8-16

Product Description

The GIBRALTAR 26395 5 is a fixed lifting eye bolt with shoulder, rated for a 1,400 lb lifting capacity and sized for a 3/8-16 thread. Built from C-1035 grade steel with a hot dipped galvanized finish, this eye bolt is fully threaded along its entire 4.5-inch shank length. The shoulder design provides a load-bearing surface against the workpiece, which is critical for maintaining proper load alignment in vertical or near-vertical lifts. This hardware is installed by riggers, millwrights, and maintenance mechanics in industrial, commercial, and heavy trade settings where secure overhead lifting points are required.

This eye bolt suits applications where a permanent or semi-permanent lifting attachment is needed through a structural member, plate, or housing. The full thread along the 4.5-inch shank allows flush seating of the shoulder against varying material thicknesses. The hot dipped galvanized finish makes it suitable for outdoor, wet, or moderately corrosive environments. Common install scenarios include machinery rigging, equipment anchoring, and load-handling setups in manufacturing, construction, and maintenance operations.

Key Features

• 1,400 lb rated lifting capacity for reliable load handling within spec
• Fixed eye design with shoulder for consistent load-bearing contact against the mounting surface
• Fully threaded 4.5-inch shank for flexible mounting depth on varied material thicknesses
• 3/8-16 thread size for compatibility with standard fastener tooling and hardware
• C-1035 grade steel construction for structural integrity under load
• Hot dipped galvanized finish for corrosion resistance in outdoor or wet environments

Compatibility

Designed as an OEM-style fixed shoulder eye bolt for use with standard 3/8-16 threaded holes in structural steel, plates, and machinery components requiring a rated vertical lifting attachment point.

Installation Notes

Installation is performed by qualified riggers or mechanics following applicable ASME B30.26 rigging hardware standards. Always thread the eye bolt fully so the shoulder seats flush and tight against the mounting surface before applying any load. Never side-load a fixed eye bolt beyond rated angular limits, and never use a bent, cracked, or deformed eye bolt. Inspect the eye bolt and all rigging connections before each lift.
