Gibraltar 26077 0 Fixed Shoulder Eye Bolt 9000 Lb 1-8 Thread

Product Description

The GIBRALTAR 26077 0 is a fixed lifting eye bolt with a full shoulder base, rated for 9,000 lb lifting capacity. Forged from Grade C-1035 steel and finished with a zinc-plated coating for corrosion resistance, this eye bolt is built for repeated rigging and overhead lifting applications. The 1-8 thread size with a fully threaded 2.5-inch shank provides solid engagement in tapped holes or with a nut and backing plate. Licensed riggers, millwrights, and maintenance professionals install this hardware in industrial and commercial lifting setups where a fixed, non-swivel anchor point is required.

This eye bolt is suited for vertical straight-line lifting in industrial plants, warehouses, fabrication shops, and construction sites. The shoulder design distributes load across the base, making it appropriate for use with lifting slings, hooks, and hoisting chains. It is intended for static vertical loads only; angled loading on a fixed eye bolt reduces rated capacity significantly and requires engineering review before use.

Key Features

• 9,000 lb rated lifting capacity for heavy-duty rigging applications
• Grade C-1035 forged steel construction for strength and durability
• Shoulder base with 1-inch shoulder diameter for load distribution
• Fully threaded 2.5-inch shank on 1-8 thread size
• Zinc-plated finish for corrosion resistance
• 1-13/16 inch eye inside diameter accommodates standard hooks and shackles

Compatibility

Designed for use in standard 1-8 threaded holes or with appropriate nuts and backing hardware in vertical overhead lifting applications across industrial and commercial settings.

Installation Notes

Installation should be performed by a qualified rigger or maintenance professional familiar with applicable ASME B30 rigging standards. Ensure the threaded hole or nut provides full thread engagement equal to at least the full shank length before applying any load. De-energize and lock out any equipment before installing or removing lifting hardware. Never exceed the rated vertical lifting capacity, and do not use this fixed eye bolt for angular or side loads without consulting a load chart and engineering guidance.
