Gibraltar 13190 2 Fixed Shoulder Eye Bolt 2600 Lb 316 Ss

Product Description

The GIBRALTAR 13190 2 is a fixed lifting eye bolt with a shoulder, designed for overhead lifting and rigging applications where a secure, load-rated attachment point is required. Constructed from Grade 316 stainless steel with an electropolished finish, this bolt delivers corrosion resistance suitable for wet, marine, and chemically active environments. It carries a rated lifting capacity of 2,600 lb and features a 1/2-13 thread size with a 3-inch fully threaded shank. Rigging professionals, millwrights, and maintenance crews install this hardware when a reliable fixed lifting point is needed on machinery, structural steel, or equipment frames.

This eye bolt is suited for industrial, commercial, and marine rigging installations where stainless steel construction is specified for corrosion resistance. The shoulder design distributes load properly at the mounting surface and is required whenever angular or side loading is possible. It is appropriate for use in food processing, offshore, wastewater, and other corrosive-environment applications where carbon steel hardware is not acceptable. Proper rigging practice requires that loading remain in-line with the plane of the eye for maximum rated capacity.

Key Features

• 2,600 lb rated lifting capacity for overhead and rigging use
• Grade 316 stainless steel construction for superior corrosion resistance
• Electropolished finish reduces surface roughness and improves corrosion performance
• Shoulder design supports proper load distribution and allows for angular loading when used in a matched set
• Fully threaded 3-inch shank provides maximum thread engagement flexibility
• 1/2-13 UNC thread size compatible with standard nuts and tapped holes

Compatibility

Designed as a fixed shoulder lifting eye bolt compatible with standard 1/2-13 UNC threaded holes and matching hex nuts in overhead lifting and rigging assemblies.

Installation Notes

Installation should be performed by a qualified rigger or maintenance professional familiar with applicable rigging standards and load ratings. The bolt must be fully seated against the shoulder before any load is applied — do not load a partially engaged or unsupported eye bolt. De-energize and lockout-tagout all equipment before installing or removing lifting hardware on machinery. Always verify that the working load limit of all rigging components in the lift assembly meets or exceeds the load being lifted.
