Genesis Cable 21171009 Multiconductor Unshielded Cable 18-19 8/C 1000 FT

Product Description

The Genesis Cable 21171009 is a riser-rated unshielded multiconductor cable suitable for metal raceways, solid bottom metal cable trays, risers, and general building installations. It features bare copper conductors, polypropylene insulation, and a PVC jacket. The cable is marked with Countdown length markings for tracking usage. Rated for sunlight exposure.

• Bare copper conductors ensure excellent conductivity.
• Features polypropylene insulation and a durable PVC jacket.
• Countdown length markings simplify usage tracking.

Product Highlights

This Genesis Cable is designed for dependable connections in security, controls, audio, and other low-voltage applications. It is riser rated and sunlight resistant.

Product Information

Standard Information

• Brand: Genesis Cable
• Manufacturer Part Number: 21171009

Technical Specifications

• Size (AWG or kcmil): 18 AWG
• No. of Conductors: 8
• Stranding: Stranded
• Shielding: Unshielded
• Nominal Total Weight (lbs/1000'): 52
• Product Type: 18/8 Wire
• Length: 1000Ft.
• Voltage: 300 Volts max Operating Voltage
• Rating: CMR, CL3R, FPLR, FT4, Sunlight Resistant
