General Electric THQB32045 Bolt-On Circuit Breaker 45A 3P

Product Description

General Electric THQB32045 is a bolt-on circuit breaker with a current rating of forty-five amps and three poles. This circuit breaker is suitable for residential and commercial applications. Its design allows for easy integration into load centers and lighting panels.

• Rated current of 45A
• Three poles for efficient circuit protection
• UL approved with a 10 kA interrupting rating

Product Highlights

The THQB32045 is a molded case thermal magnetic circuit breaker. It ensures safety and reliability through its quick-make quick-break mechanism.

Product Information

Standard Information

• Manufacturer: General Electric
• UPC: 783164059939

Technical Specifications

• Type: Molded Case, Fixed Thermal Magnetic
• Interrupting Rating: 10 kA
• Number of Poles: 3
• Amperage Rating: 45 A
• Voltage Rating: 240 VAC
• Wire Size: 8 to 3 AWG (Copper/Aluminum)
• Dimensions: 3.28 in H x 3 in W x 2.38 in D
• Terminal Type: Copper/Aluminum Load Lug, Bolt-On
• Mounting Type: Bolt-On
