GE TEY3100 Breaker Ckt Pnl Ltg 277/480VAC 100A 14KA

Product Description

The GE TEY3100 is a lighting panel circuit breaker designed for applications requiring reliable power distribution at 277/480 VAC with a rated current of one hundred amps. This unit is classified under the Q-Line series and includes a fourteen kiloamp interrupt rating. The TEY3100 features three poles and a non-interchangeable trip type.

• Compact, bolt-on design suitable for various applications.
• Integrated copper/aluminum load lug included.
• Quick-make/quick-break mechanism ensures safety during operation.

Product Highlights

This lighting panel circuit breaker provides safe and reliable power management in industrial environments.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Frame: TEY
• Voltage Rating: 277/480 VAC
• Current Rating: 100 A
• Interrupt Rating: 14 kA
• Number of Poles: 3
• Dimensions: 5-1/4 in H x 3 in W x 3-1/16 in D
• Mounting Type: Bolted-On
• Temperature Rating: 40 deg C
• Wire Size: 14 to 8 AWG, 12 to 8 AWG
