Gates 96416026 Cogged V-belt AX26 Single Band

Product Description

The GATES 96416026 is a cogged, single-band V-belt from the 9641 Series Quad-Power 4 line, designed for power transmission applications that demand reduced flex resistance and efficient torque transfer. The AX belt section type features a notched underside that lowers heat buildup and increases flexibility compared to a standard wrapped belt. With an outside length of 28 inches, this belt is sized for a wide range of industrial and HVAC drive systems. It is typically installed by mechanical contractors, HVAC technicians, and industrial maintenance professionals.

The 96416026 suits belt-driven systems where a single AX-section belt is specified, including HVAC air handling unit fan drives, compressors, pumps, and general industrial power transmission setups. The cogged design makes it compatible with smaller-diameter sheaves where a conventional belt would experience excessive bending stress. This belt is manufactured in the United States and is part of the Gates 9641 Series product family.

Key Features

• Cogged construction reduces bending resistance and heat buildup on smaller sheaves
• AX belt section with 28-inch outside length for a broad range of drive configurations
• Single-band design for direct replacement of standard AX26 V-belt applications
• 9641 Series Quad-Power 4 construction for high power capacity in a compact profile
• Manufactured in the United States

Compatibility

Designed as an OEM-style replacement for single-band AX-section cogged V-belt drive systems requiring a 28-inch outside length belt.

Installation Notes

V-belt replacement should be performed by a qualified technician with the drive system fully de-energized and locked out per OSHA lockout/tagout procedures. Never use a pry bar to force a belt onto a sheave; always adjust center distance to allow proper belt seating. After installation, verify belt tension and sheave alignment before returning the system to service. Inspect sheave grooves for wear before installing a new belt.
