Frigidaire 5304514801 Washer Cup Assembly

Product Description

The FRIGIDAIRE 5304514801 is a washer cup assembly designed to hold and dispense laundry additives during the wash cycle. Installed inside the detergent drawer housing, it provides separate compartments for detergent, fabric softener, and bleach. Internal channels direct each liquid into the wash tub at the correct cycle phase through the inlet and tubing system. The molded construction ensures a secure fit within the drawer housing, preventing spills and keeping fluid flow directed as intended. Appliance technicians and experienced DIYers install this part as a direct replacement when the existing cup is cracked, warped, or failing to dispense properly.

This cup assembly is used in residential front-load or top-load washing machines equipped with a multi-compartment detergent drawer. It supports normal wash, rinse, and spin cycle operation by releasing additives at the appropriate times. The part integrates with the existing inlet and tubing system without modification, making it a straightforward drop-in replacement during a service call or owner repair.

Key Features

• Multi-compartment design accommodates detergent, fabric softener, and bleach separately
• Molded construction provides a precise fit within the detergent drawer housing
• Internal channels direct fluid flow into the wash tub via the inlet and tubing system
• Supports correct additive release timing across wash, rinse, and spin cycles
• Direct OEM replacement part for reliable fitment and function

Compatibility

Designed as an OEM-style replacement cup assembly for FRIGIDAIRE residential washing machines equipped with a multi-compartment detergent drawer system.

Installation Notes

Installation is typically performed by an appliance repair technician or a knowledgeable DIYer. Disconnect power to the washing machine before beginning any disassembly of the drawer housing or internal components. Remove the detergent drawer fully and release any retaining clips or tabs before extracting the existing cup assembly. Verify the replacement seats flush and all channel openings align with the housing inlets before reassembling.
