Product Description
The FRIEDRICH PDH07R3SGR3 PTAC unit offers 7200 BTU cooling capacity with a 6000 BTU heat pump. This unit features 2 fan speeds for better circulation and with 265V electricity, it is for commercial use only. The two-motor design allows the indoor motor to run at slower speeds, which sharply reduces indoor sound levels.
- Features two separate motors for quieter operation.
- Includes a tangential blower wheel for efficiency.
- Equipped with a digital control pad with LCD readout.
Product Highlights
This Friedrich PTAC unit is super quiet and efficient, and can be used in both commercial and residential applications. Includes R32 refrigerant.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: PDH07R3SGR3
Technical Specifications
-
Brand: Friedrich
-
Manufacturer: Friedrich
-
Model: PDH07R3SGR3
-
Product Type: AIR_CONDITIONER
-
Product Group: Home
-
Cooling BTUs (@265V): 7200
-
Heat Pump BTUs (@265V): 6000
-
Voltage: 265-277V
-
EER (@265V): 13.0
-
COP (@265V): 3.6
-
Refrigerant Type: R32
-
Fan Speeds: 2
-
Control Type: Electronic/Digital
-
Filter Access: Top Lift Out
-
Connectivity: Not WiFi Compatible
-
Remote Control: No
-
Fresh Air Intake: Yes
-
Sleep Mode: No
-
Certifications: ULCDTP, UL, AHRI
-
Plug Face (NEMA): 7-20P
-
Circuit Breaker Size (Amps): 20
-
Cord Length: 27.5"
-
Sleeve Required for Install: Yes
-
Fits Sleeve Size (in.): 42
-
Compressor: Standard
-
Energy Star: No
-
Dehumidification (pts/hr): 1.7
-
CFMs: 282 / 312 (L / H)
-
Includes Heat Mode: Yes
-
Heat Type: Heat Pump with Back-Up Electric
-
Cooling Amps (@265V): 2.1
-
Cooling Watts (@265V): 560
-
Electric Heat Strip Size (kW - @265V): 3.5
-
Electric Heating BTUs (@265V): 11943
-
Electric Heating Amps (@265V): 13.2
-
Electric Heating Watts (@265V): 3500
-
Heat Pump Heating Amps (@265V): 1.8
-
Heat Pump Heating Watts (@265V): 490
-
Vent Location: Front Top
-
Make-Up Air: No
-
Energy Saver Mode: No
-
24 Hour ON/OFF Timer: No
-
Width (in): 42
-
Height (in): 16
-
Depth (in): 21
-
Volts: 265
-
Amps: 2.1 Amps
-
EER: 13
-
ADA Compliant: No
-
Maximum Heating Watts: 490 Watts
-
Maximum Heating Amps: 1.8 Amps
-
Maximum Cooling Watts: 2140
-
Maximum Cooling Amps: 2.1 Amps
-
Energy Efficiency Rating: 13
-
Indoor CFM, Low: 282 CFM
-
Indoor CFM, High: 311 CFM
-
PTAC: Yes
-
Volt Range: 238.5-291.5
-
Voltage (1 PHASE, 60 Hz): 265
-
Reverse Heat (Amps): 1.8
-
Power Factor: 1.0
-
Outdoor Fan Motor, HP: 0.08
-
Compressor RLA: 2.2
-
Compressor LRA: 12
-
Sensible Heat Ratio: 83%
-
Moisture Removal (pints/hr.): 1.69
-
COP (W/W): 3.6
-
Heating Watts: 490
-
Reverse Heating Btu: 6000
-
Heater Size (kW): 3.6
-
Energy Efficiency Ratio, EER: 13.0
-
Cooling Watts: 560
-
Cooling Btu: 7300
-
R-32 Charge (oz.): 27.51
-
Outdoor Air: 75
-
Indoor CFM, LOW: 282.48
-
Indoor CFM, HIGH: 311.9
-
Air Conditioner Type: PTHP
-
Manufacturer Sku: PDH07R3SGR3
-
Cord Included: Yes
-
Plug Type: NEMA 7-20
-
Controls: Electronic
-
Heat: Heat Pump
-
Heater Size (KW): 3.5 KW
-
Fits Standard 42" x 16" Sleeve: Yes
-
Product Length: 42
-
Product Width: 20.5
-
Product Height: 16
-
Wi-Fi Compatible: No
-
Automatic Restart: Yes
-
Seacoast Protection: Yes
-
Freeze Protection: Yes
-
Number of Fan Motors: 2
-
Sleeve Included: No
-
Exterior Grille Included: No
-
Front Cover Included: Yes
-
Actual Cooling BTUs @ 265V: 7300
-
CFM (Cool/Wet Coil) - High: 311.9
-
CFM (Cool/Wet Coil) - Low: 282.5
-
Net Weight: 112.5
-
Heating: Yes
-
Heating Reverse Cycle (btuh/aham): 6000
-
Cooling Area/Room Size: 300
-
Operation: Cool / Heat Pump
-
Cooling Capacity (BTUh): 7,300
-
Heat Pump Capacity (BTUh): 6,000
-
Electric Heat Capacity (BTUh): -
-
EER(2): 13.0
-
Airflow: 312 CFM
-
Fan Speed: 2 Fan Speed
-
Control: Electronic Control
