Firestone W013587732 High Temperature Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587732 is a high temperature airstroke actuator and airmount isolator. This product functions as both an actuator and a vibration isolator. The airstroke actuator provides linear and angular motion while maintaining a low profile. It is suitable for various applications including pressing, lifting, and conveying. The flexibility of this air spring allows it to adapt to industrial tasks effectively. As a vibration isolator, it reduces the adverse effects of vibration in machinery.

• Single convolution air spring
• Temperature range from zero to two hundred twenty-five degrees Fahrenheit
• Easy installation with a quarter-inch air inlet

Product Highlights

This airstroke actuator is designed for industrial use, providing reliable performance in a compact size.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587732

Technical Specifications

• Compressed Height: 2 inches
• Stroke Length Max: 2.100 inches
• Temperature Range Max: 225 °F
• Air Inlet: 1/4 inch
• Pressure Max: 100 psi
• Style No.: 131
• Forces at Stroke (100 psi): 2063 lbf @ 1 inch
• End Closure: Type 1 Bead Plate
