Firestone W013587731 Single Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587731 is a single convolute airstroke actuator designed to function as both an industrial actuator and a vibration isolator. This product provides linear and angular motion in a compact design compared to traditional air cylinders. Its flexible properties make it suitable for various applications such as pressing, conveying, and lifting. It effectively mitigates vibration, enhancing equipment performance and durability.

• Two-ply, fabric-reinforced rubber
• Flexible media
• Reduces harmful effects of vibration

Product Highlights

Ideal for industrial use, offering significant motion control and vibration isolation.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587731

Technical Specifications

• Compressed Height: 2 inches
• Stroke Length [Max]: 2.100 inches
• Force @ 1 in Stroke: 2063 lbf
• Pressure [Max]: 100 psi
• Temperature Range [Min]: -35 °F
• Temperature Range [Max]: 135 °F
• Air Inlet: 1/4 inch NPT
• End Closure: Type 1 Bead Plate
