Firestone W013587327 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587327 is designed as a double convolute airstroke actuator and airmount isolator. It excels in providing both linear and angular motion, while maintaining a low profile compared to traditional air cylinders. This actuator is suitable for various applications including pressing, conveying, lifting, and packaging. As a vibration isolator, it effectively diminishes vibrations, enhancing operational efficiency.

• Two-ply, fabric-reinforced rubber
• Flexible media for better motion control
• Effective in vibration reduction

Product Highlights

This product is essential for industrial machines, demonstrating versatility in actuating or isolating operations.

Product Information

Standard Information

• Brand: Firestone
• Part Number: W013587327

Technical Specifications

• Blind Tap Spacing: 2 3/4 in
• End Closure: Type 1 Bead Plate
• Pressure [Max]: 100 psi
• Bellows Type: Double Convolution
• Compressed Height: 2.8 in
• Force @ 1 in Stroke: 3437.5 lbf
• Force @ 3 in Stroke: 3287.5 lbf
• Air Inlet Type: NPT
• Temperature Range [Max]: 135 °F
• Temperature Range [Min]: -35 °F
• Weight: 5.5 LB
• EAN or UPC: 767555004524
