Firestone W013587312 High Temperature Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587312 is a high temperature airstroke actuator designed for industrial use. This actuator functions as a vibration isolator and provides both linear and angular motion. It is a versatile solution for various applications, including pressing, lifting, and packaging. Its low profile design makes it a preferred choice over traditional air cylinders, allowing for flexibility in tight spaces.

• Double convolution air spring design
• Capacity to reduce vibration effectively
• High-temperature bellows for durability

Product Highlights

This actuator is efficient and reliable, suitable for industrial environments where vibration control is essential.

Product Information

Standard Information

• Brand: Firestone
• Part Number: W013587312

Technical Specifications

• Air Inlet Type: NPT
• Air Inlet Size: 3/4 inches
• Max Temperature Range: 225 °F
• Force at 1 inch Stroke: 15000 lbf
• Force at 3 inch Stroke: 13200 lbf
• Stroke Length Max: 6.800 inches
• Compressed Height: 3.3 inches
• Pressure Max: 100 psi
• Weight: 22.1 lb
