Firestone W013587025 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013587025 is a double convolute airstroke actuator and airmount isolator. This air spring is designed for use in various industrial applications requiring linear or angular motion. Compared to traditional air cylinders, this actuator maintains a low profile while providing flexibility for operations such as pressing, lifting, and conveying.

• Double convolute design
• Flexible and adaptable
• Effective vibration isolation

Product Highlights

This product integrates two-ply, fabric-reinforced rubber construction to ensure strength and durability. Its flexible media allows it to be used effectively in different motion applications while reducing vibration impact on machinery.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587025

Technical Specifications

• Convolutions: Double
• Compressed Height: 3 inches
• Force @ 1 inch Stroke: 1812.5 lbf
• Force @ 3 inch Stroke: 1100 lbf
• Air Inlet: 1/4 inch
• Pressure [Max]: 100 psi
• Temperature Range [Max]: 135 °F
• Temperature Range [Min]: -35 °F
