Firestone W013586956 Double Convolute Airstroke Actuator Airmount Isolator

Product Description

Firestone W013586956 is a double convolute airstroke actuator and airmount isolator. This product is designed for various industrial applications. It serves as an actuator offering low-profile linear or angular motion. The flexible design allows it to handle various tasks on machines for pressing, tensioning, lifting, and packaging. Additionally, it acts as a vibration isolator, significantly reducing vibration impacts.

• Two-ply, fabric-reinforced rubber
• Flexible media for motion
• Reduces harmful vibration effects

Product Highlights

This actuator is versatile for industrial use and is effective for applications including presses, conveyors, and lifts.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013586956

Technical Specifications

• Compressed Height: 3 in
• Air Inlet: 3/4 in
• Max Pressure: 100 psi
• Temperature Range: -35 °F to 135 °F
• Force @ 1 in Stroke: 2039 lbf
• Force @ 3 in Stroke: 1786 lbf
• Convolutions: Double
• Bumpers: None
