Firestone W013586955 Double Convolute Airstroke Actuator Airmount Isolator

Product Description

Firestone W013586955 is an industrial actuator and vibration isolator that meets diverse application needs. This double convolute airstroke actuator provides efficient motion control in tight spaces, unlike air cylinders, making it suitable for various machinery tasks.

• Acts as an industrial actuator and vibration isolator
• Offers low-profile linear or angular motion
• Utilized in machines for pressing, lifting, and packaging

Product Highlights

Firestone air springs are recognized for their flexible properties. They effectively reduce vibration while performing tasks in industrial settings.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013586955

Technical Specifications

• Compressed Height: 3 inches
• Air Inlet Type: NPT
• Pressure [Max]: 100 psi
• Temperature Range [Max]: 135 °F
• Temperature Range [Min]: -35 °F
• Force @ 1 in Stroke: 2082 lbf
• Force @ 3 in Stroke: 1667 lbf
• Stroke Length [Max]: 4 inches
