Firestone W013586952 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013586952 is an air spring designed for various industrial applications. This product serves as both an actuator and a vibration isolator. It provides linear and angular motion, which is advantageous in low-profile settings compared to traditional air cylinders. The flexible rubber construction makes it suitable for machines that perform pressing, tensioning, rolling, conveying, lifting, and packaging tasks. Additionally, it efficiently mitigates harmful vibration effects.

• Two-ply fabric reinforced rubber
• Flexible media
• Reduces harmful effects of vibration

Product Highlights

The actuator is designed for industrial use, effective in conveying systems and lifting equipment.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013586952

Technical Specifications

• Compressed Height: 3 inches
• Stroke Length [Max]: 8 inches
• Force @ Maximum Stroke (100 psi): 2653 lbf
• Temperature Range [Max]: 135 °F
• Temperature Range [Min]: -35 °F
• Air Inlet: 3/4 inches
• Style No.: 20-2
• Convolutions: Double
