Firestone W013586951 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013586951 is a double convolute airstroke actuator and airmount isolator. This device acts as both an industrial actuator and a vibration isolator. It provides linear and angular motion with a low profile, suitable for various applications, including pressing, lifting, and packaging.

• Two-ply, fabric-reinforced rubber design
• Flexible media for effective motion control
• Reduces harmful effects of vibration

Product Highlights

Utilized across numerous industries, this actuator enhances equipment performance by minimizing vibration and providing smooth operation.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013586951

Technical Specifications

• Compressed Height: 3 inches
• Stroke Length (Max): 8 inches
• Max Pressure: 100 psi
• Force @ 1 in Stroke: 5156 lbf
• Force @ 3 in Stroke: 4691 lbf
• Temperature Range (Min): -35 °F
• Temperature Range (Max): 135 °F
• Blind Tap Spacing: 3.5 inches
