Firestone W013583403 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

Firestone W013583403 is a double convolute airstroke actuator and airmount isolator designed for industrial applications. It provides effective linear and angular motion in a compact design, suitable for various machinery operations. This product excels in tasks that involve pressing, conveying, and lifting while also offering vibration isolation.

• Two-ply, fabric-reinforced rubber construction
• Works effectively as both an actuator and isolator
• Compatible with various industrial applications

Product Highlights

Firestone's innovative design allows for flexibility and durability in tough industrial settings.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013583403

Technical Specifications

• Compressed Height: 2.8 in
• Stroke Length [Max]: 4.900 in
• Weight: 5.0 LB
• Force @ 1 in Stroke: 2350 lbf
• Force @ 3 in Stroke: 1760 lbf
• Air Inlet: 3/4 in
• Pressure [Max]: 100 psi
• Temperature Range [Max]: 135 °F
• Temperature Range [Min]: -35 °F
