Field Controls MAC-1 Field Wireable Connector

Product Description

The Field Controls MAC-1 is a field wireable connector designed for versatile wiring applications. It features a coupling nut sized 1/2-20UN2 and a dual keyway for efficient usability. This male straight connector has three poles and supports an amperage rating of four amps. It is suitable for wire sizes ranging from eighteen to twenty-four AWG.

• Field wireable connector with three poles
• Supports four amps and accommodates wire sizes from eighteen to twenty-four AWG
• Rated IP67 for dust and water protection

Product Highlights

The MAC-1 connector is built for durability and reliable performance, featuring a nickel-plated brass shell and coupling nut. It is ideal for environments that require shielding and protection against dust and water ingress.

Product Information

Standard Information

• Product Type: Cables
• Component Type: Field Wireable

Technical Specifications

• Series: MAC (C-coded)
• Pin Count: 3
• Gender: Male
• Head 1 Orientation: Male Straight
• Head 1 Mating Thread Type: 1/2-20UN2
• Amperage Rating: 4
• Voltage Rating: 250
• Upper AWG: 18
• Lower AWG: 24
• IP Rating: IP67
