Ferraz Shawmut TRM2-1/2 Time Delay Midget Fuse 250VAC 2.5A

Product Description

The Ferraz Shawmut TRM2-1/2 is a time-delay midget fuse with a voltage rating of two hundred fifty volts AC and a current rating of two point five amps. This fuse is designed to handle high inrush current and includes a twelve-second delay at two hundred percent of the rated load. It features a ferrule terminal and is suitable for protecting small motors, transformers, lighting circuits, and other devices that encounter high inrush loads.

• Time delay characteristic for high inrush applications
• Interrupting rating of ten kiloamperes
• Compatible with various mounting types

Product Highlights

Use this fuse to provide reliable time delay in circuits subject to high inrush currents.

Product Information

Standard Information

• Brand: Ferraz Shawmut
• Series: TRM

Technical Specifications

• MPN: TRM2-1/2
• Voltage Rating: 250 VAC
• Current Rating: 2.5 A
• Interrupting Rating: 10 kA
• Fuse Class: Midget
• Speed/Characteristic: Time Delay
• Terminal Type: Ferrule
• Mounting Type: Clip
• Product Length: 1.5 inches
• Product Diameter: 0.41 inches
• Product Weight: 0.012 lbs
• Approvals: UL listed to standard 248-14, CSA Certified to standard C22.2 No. 248.14
• Operating Temperature: 176°F (80°C)
• Storage Temperature: -13°F to 176°F (-25°F to 80°F)
• REACH Compliant: Yes
• ROHS Compliant: Yes
